• Operation Class: D
• Number Of Channels: 01
• Maximum Power:
@ 14.4 Vdc - 1 Ohm: 15000 W Rms
@ 14.4 Vdc - 2 Ohms: 8505 W Rms
• Input Sensitivity: 280mV
• Signal to Noise Ratio:> 95Db
• Frequency Response: 8Hz to 250Hz (-3Db)
• Crossover High Pass (Hpf): Variable, 8 to 30Hz (-12Db / 8th)
• Crossover Low Pass (Lpf): Variable, 60 to 250Hz (-12Db / 8th)
• Bass Boost: Parametric, 35 - 60Hz, 0 ~ + 12Db
• Efficiency: 80%
• Input Impedance: 22K Ohms
• Protection System: Short On Output, Short On Output Regarding Gnd, Low Impedance Protection, High / Low Voltage Protection And Thermal Protection.
• Min. Supply Voltage: 9 Vdc
• Maximum Power Rating: 17 Vdc
• Consumption At Rest: 400 mA
• Musical Maximum Consumption: 651 Amp
• Maximum Consumption in Sinusoidal Signal: 1302 Amp
• Dimensions (WxDxH): 238 X 71 X 544 mm
• Weight: 9.7 kg
